CSRayzer's XFP EDFA is designed for single channel or narrow band signal amplification in telecom, datacom or CATV applications. It is designed to be compatible with XFP MSA (INF-8077i) on mechanical and electrical interface, which allow it be plug-and-play in XFP cage, to save EDFA chassis. It can support up to 21dB Gain and 15dBm output power. It supports both ACC (Auto pump Current Control) and APC (Auto output Power Control) control mode.
Product Feature
1) APC/ACC operation mode
2) Low noise figure and power consumption
3) High stability and reliability
4) Customizable
Main Application
1) Telecom or datacom
2) CATV or SDH system
CSRayzer's XFP EDFA is designed for single channel or narrow band signal amplification in telecom, datacom or CATV applications. It is designed to be compatible with XFP MSA (INF-8077i) on mechanical and electrical interface, which allow it be plug-and-play in XFP cage, to save EDFA chassis. It can support up to 21dB Gain and 15dBm output power. It supports both ACC (Auto pump Current Control) and APC (Auto output Power Control) control mode.
Product Feature
1) APC/ACC operation mode
2) Low noise figure and power consumption
3) High stability and reliability
4) Customizable
Main Application
1) Telecom or datacom
2) CATV or SDH system
Parameter | Unit | Min | Type | Max |
Wavelength | nm | 1530 | - | 1560 |
Input power | dBm | -6 | 6 | |
Output power | dBm | 15 | ||
Noise Figure | dB | 5 | 6 | |
Operation temperature | ℃ | 0 | 70 | |
Storage temperature | ℃ | -40 | 85 | |
Supply voltage | V | 3.14 | 3.3 | 3.47 |
Power consumption | W | 2.5 | 3.5 |
Parameter | Unit | Min | Type | Max |
Wavelength | nm | 1530 | - | 1560 |
Input power | dBm | -6 | 6 | |
Output power | dBm | 15 | ||
Noise Figure | dB | 5 | 6 | |
Operation temperature | ℃ | 0 | 70 | |
Storage temperature | ℃ | -40 | 85 | |
Supply voltage | V | 3.14 | 3.3 | 3.47 |
Power consumption | W | 2.5 | 3.5 |
