Parameter | Unit | Value | Remark | |||
Channel Number | 4 | 8 | ||||
Operating Wavelength Range | nm | C Band | ||||
Channel Spacing | GHz | 100G | ||||
Channel Bandwidth | nm | ITU λc ± 0.11 | ||||
Insertion Loss with DWDM channel | dB | ≤1.5 | ≤2.0 | |||
Adjacent Isolation | dB | ≥30 | ||||
Non-Adjacent Isolation | nm | ≥40 | ||||
Passband Ripple | dB | ≤0.5 | ≤0.4 | |||
Polarization Dependent Loss | dB | ≤0.5 | ||||
Directivity | dB | ≥50 | ||||
Return Loss | dB | ≥45 | ||||
Operating Power | mW | ≤300 | ||||
Fiber Length | cm | 150 ±10 | ||||
Fiber Type | / | G657 A1 Grade With 900um Loose Tube, White | ||||
Connector | / | N/A or by Specified | ||||
Package Dimension | mm | 30x20x7 | ||||
Working Temp. | ℃ | -5~+75 |
Parameter | Unit | Value | Remark | |||
Channel Number | 4 | 8 | ||||
Operating Wavelength Range | nm | C Band | ||||
Channel Spacing | GHz | 100G | ||||
Channel Bandwidth | nm | ITU λc ± 0.11 | ||||
Insertion Loss with DWDM channel | dB | ≤1.5 | ≤2.0 | |||
Adjacent Isolation | dB | ≥30 | ||||
Non-Adjacent Isolation | nm | ≥40 | ||||
Passband Ripple | dB | ≤0.5 | ≤0.4 | |||
Polarization Dependent Loss | dB | ≤0.5 | ||||
Directivity | dB | ≥50 | ||||
Return Loss | dB | ≥45 | ||||
Operating Power | mW | ≤300 | ||||
Fiber Length | cm | 150 ±10 | ||||
Fiber Type | / | G657 A1 Grade With 900um Loose Tube, White | ||||
Connector | / | N/A or by Specified | ||||
Package Dimension | mm | 30x20x7 | ||||
Working Temp. | ℃ | -5~+75 |
Parameter | Unit | Specification |
Channel Spacing | GHz | 100 |
Operating Wavelength | nm | 1520~1570 |
Center Wavelength | nm | C31~C34 |
CW accuracy @23℃ | nm | ±0.1 |
Channel Clear Pass-band | nm | ITU±0.11 |
Insertion Loss | dB | ≤2.0 |
Channel Isolation (adj) | dB | ≥30 |
Channel Isolation (non-adj) | dB | ≥40 |
Return Loss | dB | ≥45 |
Directivity | dB | ≥50 |
Polarization Dependent Loss | dB | ≤0.2 |
Polarization Mode Dispersion | ps | ≤0.1 |
Fiber Type | / | G657A1 SM,900μm loose tube |
Fiber Length | m | 1 |
Connector Type | / | FC/APC |
Module BOX Dimension | mm | 100×80×10 (ABS box) |
Operating temperature | °C | -5~+75 |
Storage temperature | °C | -40~+85 |
MAX. Optical Power | mW | 500(COM) |
Parameter | Unit | Specification |
Channel Spacing | GHz | 100 |
Operating Wavelength | nm | 1520~1570 |
Center Wavelength | nm | C31~C34 |
CW accuracy @23℃ | nm | ±0.1 |
Channel Clear Pass-band | nm | ITU±0.11 |
Insertion Loss | dB | ≤2.0 |
Channel Isolation (adj) | dB | ≥30 |
Channel Isolation (non-adj) | dB | ≥40 |
Return Loss | dB | ≥45 |
Directivity | dB | ≥50 |
Polarization Dependent Loss | dB | ≤0.2 |
Polarization Mode Dispersion | ps | ≤0.1 |
Fiber Type | / | G657A1 SM,900μm loose tube |
Fiber Length | m | 1 |
Connector Type | / | FC/APC |
Module BOX Dimension | mm | 100×80×10 (ABS box) |
Operating temperature | °C | -5~+75 |
Storage temperature | °C | -40~+85 |
MAX. Optical Power | mW | 500(COM) |
