100G DWDM Module

Name：32CH 100G DWDM Module

P/N： MD1-DC23-32CL-11

Related Products

OUR FOCUS

CONTACT US

The core team of the company is composed of experienced academics and industry elites.

Parameter	Unit	Value	Remark
Name	/	32CH 100G DWDM Module
Channel Spacing	/	100 GHz
Operation Wavelength	/	C band
Center Wavelength	nm	ITU C23~C54
Channels	/	1×32
Operation Bandwidth	nm	ITU±0.11
Insertion Loss	dB	≤5.0
Adjacent Channel Isolation	dB	≥30
Non-adjacent channel isolation	dB	≥45
Return Loss	dB	≥45
Directivity	dB	≥50
PDL	dB	≤0.2
Polarization Mode Dispersion	ps	≤0.2(DG)
Optical Power	mW	≤500（COM）
Fiber Type	/	G657A1，900μm Loose Tube
Fiber Length	cm	100 ±10
Connector	/	FC/APC
Package Dimension	mm	120×80×18	Metal Box
Working Temp.	℃	-40~+85
Storage Temp.	℃	-40~+85
