Availability: | |
---|---|
Features:
a. High power output
b. Metal-coupled and hermetic package
c. TEC inside
d. Polarization-maintaining or single-mode optical fiber
e. 8pin/6pin butterfly package
Applications
a. Fiber-optic gyroscope
b. Optic test
c. Optical fiber transmission system
d. Fiber-optic sensor
e. OCT
Features:
a. High power output
b. Metal-coupled and hermetic package
c. TEC inside
d. Polarization-maintaining or single-mode optical fiber
e. 8pin/6pin butterfly package
Applications
a. Fiber-optic gyroscope
b. Optic test
c. Optical fiber transmission system
d. Fiber-optic sensor
e. OCT
Parameter | Symbol | Min | Typ | Max | Unit | Test Conditions |
Optical Output Power | Po | 0.2 | -- | 3.0 | mW | Iop=100mA |
Forward Voltage | VF | -- | 1.2 | -- | V | Iop=100mA |
Center Wavelength | λc | -- | 1310 | -- | nm | Iop=100mA |
Bandwidth FWHM | Bw | 30 | 40 | - | nm | Iop=100mA |
Spectral Ripple | -- | -- | 0.2 | dB | Iop=100mA | |
Polarization Extinction Ratio | PER | -- | -- | 1.5 | dB | Low Polarization Rate |
Thermistor Resistance | RT | 9.5 | 10.0 | 10.5 | KΩ | T=25 °C |
Thermistor B-Value | -- | 3950 | -- | K | 25℃/85℃ | |
Po Tracking Error | Po TE | -- | 6% | 10% | -45~70℃ -55~70℃ | |
Wavelength Tracking Error | λc TE | -- | 0.5 | 1 | nm | -45~70℃ -55~70℃ |
